Elektrische Höhenverstellung (option)
Ersatzteile (31 Teile)
1
1739-554-520-00
2
1739-554-370-00
3
CYLINDER/TXG ASSY
4
PISTON
5
STOPPER,PISTON
6
PACKING,ROD
7
DUST/SEAL
8
ADAPTER/90DEG/PUMP
9
HOSE/1500 ASSY
10
1739-554-003-00
11
PIN/15X72
12
V201-361-203-50
13
BOLT/M12X20/7T
14
WASHER,SP/M12
15
1739-554-350-00
16
1739-554-360-00
17
NIPPLE,GREASE
18
WASHER/33X44X02
19
RING,SNAP/32 C
20
PIN/15X60
21
WASHER,PL/M14
22
PIN,SPLIT/3X25
23
1739-554-005-00
24
CLAMP/28X55
25
1342-402-006-00
26
ADAPTER/L/G1/4 ASSY
27
O-RING/1B,P11
28
ARM/LIFT/RH
29
BOLT
30
WASHER,SP/M12
31
1725-553-720-10
