Elektrische Höhenverstellung (option)
Ersatzteile (38 Teile)
1
1739-555-400-00
2
1739-555-210-00
3
BOLT
4
WASHER,SP/M14
5
V201-361-203-50
6
BOLT/M12X40/7T
7
V304-460-012-00
8
WASHER,SP/M12
9
CYLINDER/TXG ASSY
10
PISTON
11
STOPPER,PISTON
12
PACKING,ROD
13
DUST/SEAL
14
PIN/15X72
15
1739-555-002-00
16
1739-555-001-00
17
V211-260-801-60
18
3768-185-022-20
19
HOSE/1500 ASSY
20
V211-260-801-60
21
V211-260-804-00
22
ADAPTER/L/G1/4 ASSY
23
O-RING/1B,P11
24
V363-260-008-00
25
CLAMP/28X55
26
1342-402-006-00
27
1739-555-220-00
28
BUSH/25X28X15
29
ROD/LINK COMP
30
BUCKLE/TURN/M16
31
NUT/M16
32
3650-152-009-00
33
NIPPLE,GREASE
34
PIN/25X71
35
PIN/15X60
36
WASHER,PL/M14
37
PIN,SPLIT/3X25
38
1739-555-240-00
