Front PTO
Ersatzteile (51 Teile)
1
PTO-Gehäuse
2
BOLT,SP/M10X30/7T
3
Welle
4
V600-450-620-40
5
BEARING,RB/6206SS
6
RING,SNAP/R62
7
Welle
8
COUPLING/18X30X55
9
Schutz, Front PTO, 540
10
FLANGEBOLT/M8X16
11
Lagerbock
12
BOLT,SP/M10X30/7T
13
Welle, PTO
14
V600-450-620-40
15
V600-450-620-50
16
RING,SNAP/52 C
17
1771-244-004-20
18
V211-561-003-00
19
Keilriemen
20
PULLEY/V2B155
21
KEY/08X07X20
22
WASHER
23
WASHER,SP/M16
24
NUT/M16
25
PIN/TENSION
26
WASHER,SP/M12
27
V411-260-012-00
28
1771-244-250-10
29
BUSH/15X17X11
30
PULLEY/FT80X47
31
Sicherungsring 15x1
32
BOLT/M8X45/7T
33
NUT/M8
34
Feder
35
WASHER
36
Sicherungsring 15x1
37
PIN/TENSION
38
WASHER,SP/M12
39
V411-260-012-00
40
ARM/PTOBRAKE ASSY
41
BUSH/15X17X11
42
SPRING/HT033
43
WASHER
44
Sicherungsring 15x1
45
Bremsklotz
46
V301-260-006-00
47
V401-160-006-00
48
1771-244-240-30
49
BOLT,SP/M8X20
50
1771-244-290-10
51
BOLT,SP/M8X16
