Kabelbaum, Schalter
Ersatzteile (39 Teile)
1
1782-690-500-10
2
1782-690-502-00
3
1782-690-510-00
4
FUSE/SLOW BLOW/40A
5
DIODE/3A
6
FUSE/BLADE/32V10A
7
FUSE/BLADE/32V05A
8
BOLT,SP/M8X16
9
BULB/12V3.4W
10
1782-690-250-20
11
COVER/BATTERY
12
1782-690-253-00
13
1782-690-254-00
14
COVER/BATTERY/STARTO
15
1650-650-295-00
16
1650-650-296-00
17
1560-666-005-00
18
1560-666-006-00
19
NUT/M8
20
WASHER,SP/M8
21
CABLE/EARTH ASSY
22
V211-661-002-00
23
RELAY/4P-2 ASSY
24
V210-360-601-20
25
1342-402-006-00
26
BAND,WIRE/140
27
1593-623-003-00
28
SWITCH/PUSH ASSY
29
NUT
30
BUZZER
31
V210-360-601-20
32
SWITCH,MERIT
33
SCREW/M03X20
34
PLATE,SWITCH
35
V210-360-602-50
36
Bremslichtschalter
37
ARM
38
BOLT,SP/M6X16
39
1782-690-051-10
